Buy Chloride Solar 10.24kWh 51.2V LiFePO₄ Lithium Solar Battery CS-10H; Built-in BMS, 200Ah, 10kW Max Discharge, IP20, CAN/RS485, Wall-Mounted, Scalable up to 8 Units (81.92kWh) in Uganda
Description Chloride Solar 10.24kWh 51.2V LiFePO₄ Lithium Solar Battery CS-10H Technical Specifications Model: CS-10H Battery Chemistry: LiFePO₄ (Lithium Iron Phosphate) Total Energy: 10.24kWh Usable Energy (DC): 8.7kWh Rated Capacity: 200Ah Nominal Voltage: 51.2Vdc Voltage Range: 48–56Vdc Maximum Discharge Power: 10kW Cycle Life: 6000 cycles @ 80% DoD Parallel / Series Support: Up to 8 units Communication: CAN / RS485 Cooling Type: Ambient cooling IP Rating: IP20 Installation: Wall-mounted Dimensions (W × D × H): 700 × 500 × 235 mm Weight: 87 ±1kg Operating Temperature (Charge): 0°C to 45°C Operating Temperature (Discharge): -10°C to 55°C Relative Humidity: 0–95% (non-condensing) Case Material: Metal Safety Certification: UN3480, CE Warranty: 10 Years
Chloride Solar 10.24kWh 51.2V LiFePO₄ Lithium Solar Battery CS-10H 10.24 kWh lithium iron phosphate (LiFePO₄) energy storage module. 51.2V low-voltage system compatible with 48V hybrid inverters. 8.7 kWh usable energy under standard operating conditions. Built-in intelligent BMS with accurate voltage and current sampling. 10kW maximum discharge power for high-load support. 200Ah rated capacity for stable energy delivery. Expandable up to 8 units (81.92kWh total system capacity). CAN / RS485 communication for inverter integration. IP20-rated wall-mounted metal enclosure for indoor installation. ≥6000 cycle life at 80% depth of discharge with 10-year warranty support.
