Buy new Deye 5.12kWh 51.2V LiFePO₄ Lithium Solar Battery RW-L5.1; Built-in BMS, 100Ah, 100/120A Charge/Discharge, IP65, CAN/RS485, Wall-Mounted, Scalable up to 32 Units (163.84kWh) in Uganda - - Free

Ask about this product

0 /5.0 (0 reviews)

People are viewing right now

Pricing

Ugx 3,900,000 /pc

100 available

Minimum order qty 1

QTY

Inhouse product

Message Seller

Description Deye 5.12kWh 51.2V LiFePO₄ Lithium Battery RW-L5.1 datasheet Electrical Specifications Battery Chemistry: LiFePO₄ Nominal Voltage: 51.2V Operating Voltage Range: 44.8 – 57.6V Capacity: 100Ah Nominal Energy: 5.12kWh Usable Energy (90% DoD): 4.61kWh Max Continuous Charge Current: 100A Max Continuous Discharge Current: 120A Peak Charge/Discharge Current: 200A (10 seconds) Recommended Depth of Discharge: 90% Scalability & Integration Maximum Parallel Units: 32 Maximum Total Energy (32 units): 163.84kWh Communication Ports: CAN2.0, RS485 Compatible with Deye hybrid inverters and other supported systems Battery module auto-networking (no DIP switches required) Safety & Protection Built-in intelligent BMS Integrated 125A 1P DC circuit breaker (60Vdc) Cell balancing and temperature protection Residual current and system protection integration via inverter Environmental & Installation Installation: Wall-mounted or floor-mounted Ingress Protection: IP65 Operating Temperature: Charge: 0°C to 55°C Discharge: -20°C to 55°C Recommended Operating Temperature: 15°C to 35°C Storage Temperature: 0°C to 35°C Relative Humidity: ≤95% Permissible Altitude: ≤2000m Physical Specifications Dimensions (W × H × D): 420 × 680 × 160 mm Weight: 50 kg Deye 5.12kWh 51.2V LiFePO₄ Lithium Battery RW-L5.1 5.12kWh lithium iron phosphate (LiFePO₄) energy storage module. 51.2V low-voltage system compatible with hybrid inverters. 4.61 kWh usable energy at 90% depth of discharge. Built-in intelligent BMS for cell balancing and protection. 100A continuous charge / 120A continuous discharge capability. 200A peak discharge (10 seconds) for high-load support. Built-in 125A DC circuit breaker for added safety. Scalable up to 32 units (163.84kWh total capacity). IP65-rated enclosure for indoor and outdoor installation. ≥6000 cycle life at 90% DoD with 10-year warranty support.
