Buy new Luminous 550-Watt 24V Monocrystalline Solar Panel LUM550M144; Voc 49.60V, Vmp 40.83V, Imp 13.48A, Isc 14.04A, Module Efficiency 21.28% in Uganda - - Free Delivery > Long warranty > Lifetime Af

Ask about this product

0 /5.0 (0 reviews)

People are viewing right now

Pricing

Ugx 390,000 /pc

100 available

Minimum order qty 1

QTY

Inhouse product

Message Seller

Description Luminous 550-Watt 24V Monocrystalline Solar Panel LUM550M144 Full Specifications Electrical Characteristics Maximum Power (Pmax): 550W Max-Power Voltage (Vmp): 40.83V Max-Power Current (Imp): 13.48A Open-Circuit Voltage (Voc): 49.60V Short-Circuit Current (Isc): 14.04A Module Efficiency: 21.28% Operating Temperature: -40℃ to +85℃ Maximum System Voltage: 1500V Maximum Series Fuse Rating: 25A Power Tolerance: ±5% Temperature Characteristics Nominal Module Operating Temperature (NMOT): 45℃ ± 2℃ Temperature Coefficient of Pmax: -0.35%/℃ Temperature Coefficient of Voc: -0.27%/℃ Temperature Coefficient of Isc: 0.048%/℃ Mechanical Characteristics Cell Type: Monocrystalline 182×91mm Number of Cells: 144pcs Dimensions: 2279×1134×35mm Weight: 28.9kg Front Cover: 3.2mm Anti-Reflective, High Transmission Tempered Glass Frame Material: Anodized Aluminium Alloy Junction Box: IP68 Rated Output Cables: 4.0 mm², Wire Length 300mm Packaging Packing: 31PCS/Pallet, 620PCS/40’HQ Key specifications of Luminous 550-Watt 24V Monocrystalline Solar Panel LUM550M144 550W Monocrystalline Solar Panel with high efficiency 21.28% Module Efficiency for maximum energy output 49.6V Open-Circuit Voltage (Voc), 13.48A Max-Power Current (Imp) Half-Cut Multi-Busbar Technology for improved shading tolerance IP68 Junction Box & Anodized Aluminium Frame for durability Withstands Harsh Conditions (TUV Certified, -40°C to +85°C Operating Temperature)
