Hikvision DVR 4 Channel 1080p Full HD (DS-7204HGHI-F1). Recording Video compressionH.264+/H.264 Encoding resolutionWhen 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF,When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF Frame rateMain stream: ,When 1080p Lite mode not enabled:,For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),When 1080p Lite mode enabled:,1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),Sub-stream: ,2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N), Video bit rate32 Kbps to 4 Mbps Dual streamSupport Stream typeVideo, Video & Audio Audio compressionG.711u Audio bit rate64 Kbps Video and Audio IP video input1-ch (up to 5-ch) Up to 960p resolution Support H.264+/H.264 IP cameras Analog video input4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection Turbo HD input1080p25, 1080p30, 720p25, 720p30 AHD input1080p25, 1080p30, 720p25, 720p30 HDCVI input1080p25, 1080p30, 720p25, 720p30 CVBS inputSupport Audio input1-ch, RCA (2.0 Vp-p, 1 KΩ) Audio output1-ch, RCA (Linear, 1 KΩ) Two-way audioReuse the first audio input Synchronous playback4-ch VGA/HDMI output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz Network Remote connections32 Network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS Network interface1, RJ45 10M/100M self-adaptive Ethernet interface Auxiliary interface SATA1 SATA interface CapacityUp to 6 TB capacity for each disk Alarm in/outN/A USB interfaceRear panel: 2 × USB 2.0 General Power supply12 VDC Working temperature-10 °C to 55 °C (14 °F to 131 °F) Working humidity10% to 90% Weights (without HDD)≤ 1 kg (2.2 lb) Consumption(without HDD)≤ 8 W Dimensions(W × D × H)260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) Key Features: Hikvision DVR 4 Channel 1080p Full HD (DS-7204HGHI-F1). l Support H.264+/H.264 video compression l Support HDTVI/AHD/CVI/CVBS/IP video input l Up to 5-ch 960p IP camera input for DS-7204HGHI-F1, up to 10/18-ch 1080p IP camera input for DS-7208/7216HGHI-F1 l Max. 1200 m for 720p HDTVI signal Color: Black
